ASTM A269 TP316L / UNS S31603 / 1.4404 Stainless Steel Tube Bright Annealed Tube

Product Categories
Yuhong Group Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

ASTM A269 TP316L / UNS S31603 / 1.4404 Stainless Steel Tube Bright Annealed Tube

Brand Name : YUHONG

Model Number : ASTM A269 TP316L Bright Annealed Stainless Steel Tube

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Place of Origin : CHINA

MOQ : 500KGS

Payment Terms : L/C,T/T

Delivery Time : 7 DAYS

Packaging Details : Plywood case

Product Name : Bright Annealed Tube

Standard : ASTM A269 / ASME SA269

Material : TP304/304L/304H, TP310S/310H, TP316L/316H/316Ti ,TP317/317L , TP321/321H, TP347/347H 904L , 2205, 2507, S31803, S32750, S32760

Length : Single Random, Double Random & Cut Length.

Shape : Round, Square, Rectangular, etc.

Surface : Bright Annealed (BA), Pickled And Annlealed , Polished

End : Plain Ends / Beveled Ends

Type : Seamless, Welded

Application : Instruments, Equipments, Machinery, etc

High Light : ASTM A269 TP316L Stainless Steel Seamless Tube, Bright Annealed Tube

Contact Now

ASTM A269 TP316L / UNS S31603 / 1.4404 Bright Annealed Stainless Steel Tube

A STAINLESS STEEL 316L BRIGHT ANNEALED TUBE is a corrosion-resistant pipe defined by its low carbon content (0.03% max) and 2-3% molybdenum, enhancing resistance to chlorides and acids. The "Bright Annealed" finish means it was heat-treated in a controlled, oxygen-free atmosphere, resulting in a smooth, shiny, scale-free surface without needing pickling. This pristine surface is ideal for hygienic, high-purity, and aesthetic applications in industries like pharmaceuticals, food and beverage, and semiconductors, where both superior corrosion resistance and a clean, reflective appearance are critical.


Advantages Summary
  • Superior Corrosion Resistance: Especially against chlorides and in welded conditions.
  • Excellent Surface Finish: Clean, smooth, and highly reflective.
  • High Hygienic Quality: Easy to sterilize and clean.
  • Good Mechanical Properties: Strong and ductile.
  • Good Weldability: Can be readily welded using common techniques.


ASTM A269 TP316L Bright Annealed Tube Specifications

Specifications ASME SA/ASTM A213 / A249 / A269 / A312
Dimensions ASTM, ASME
Material Grades

Dtainless steel grades:
ASTM / AISI: 316 /316L, 304/304L, 321/321H, 316Ti, 347 / 347H;
EN/DIN: 1.4301/1.4307, 1.4401/1.4404, 1.4541/1.4878, 1.4571.
Duplex/ super duplex stainless steel grades:
ASTM / AISI: S31803, S32750,S32760, 2205, 904 / 904L.
EN/DIN: 1.4462, 1.4410, 1.4539.

Nickel Alloy Steel grades:

monel 400, inconel 600, 625, 825, etc
Schedule SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Wall Thickness Schedule 5S - Schedule XXS.
Size 1/2"NB - 24"NB
Length Single Random, Double Random & Cut Length
Types Seamless/weld
Form Round, Square, Rectangular, Hydraulic Etc

ASTM A269 TP316L Bright Annealed Tube Stainless Steel Seamless/Welded Tube

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 316L 1.4404 / 1.4435 S31603 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3


ASTM A269 TP316L Bright Annealed Tube Chemical Composition Stainless Steel Seamless/Welded Tube

Grade C Mn Si P S Cr Mo Ni Fe
SS 316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.89 min


ASTM A269 TP316L Bright Annealed Tube Mechanical Properties Stainless Steel Seamless/Welded Tube

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1399 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

Applications

Stainless steel bright annealed tube is broadly used in applications (such as instruments, equipments, machinery) where requires high cleanliness inside surface, high precision dimensions, high corrossion resistance in various industries such as gas, chemical, shipbuilding, automobile,etc.

1. Food industry
2. chloride environments
3. Fasteners
4. Pharmaceuticals
5. Marine applications
6. Architectural applications
7. Medical implants which comprise pins, screws and orthopedic implants like total hip and knee replacements.

ASTM A269 TP316L / UNS S31603 / 1.4404 Stainless Steel Tube Bright Annealed Tube


Product Tags:

TP316L Bright Annealed Tubing



Bright Annealed Stainless Steel Tubing



UNS S31603 Bright Annealed Tubing


Quality ASTM A269 TP316L / UNS S31603 / 1.4404 Stainless Steel Tube Bright Annealed Tube for sale

ASTM A269 TP316L / UNS S31603 / 1.4404 Stainless Steel Tube Bright Annealed Tube Images
